Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric / Xycom / Xembedded / Acromag (varies by supply) |
| Model Number | XVME-230 |
| Product Type | Intelligent Counter Module (VMEbus-compatible I/O card) |
| Function | High-performance counting and measurement module for industrial data acquisition and control systems |
| Bus Interface | VMEbus (VMEbus compatible) |
| Processor | 10 MHz 68000 CPU onboard |
| Digital Counting Channels | 16 independent counting channels |
| Counting Rate | Up to 5 MHz |
| Programmable Counting Circuits | 4 circuits, 4 CLOCK + 4 GATE inputs each |
| Measurement Functions | Period, frequency, pulse width, position, duty cycle |
| Control Functions | Stepper motor control, frequency output, one-shot output, frequency division, periodic interrupt |
| Power Supply | +5 V DC @ ~4.6 A typical, 5.2 A max |
| Operating Temperature | 0 °C to ~64 °C typical (industrial range) |
| Storage Temperature | −40 °C to +85 °C typical |
| Humidity | 20 % to 90 % RH non-condensing |
| Vibration & Shock | Industrial vibration and shock tolerances specified in standard VME module tests |
| VME Compliance | IEEE 1014 Rev.C standard, supports A24/A16:D16 and DTB Slave |
| Dimensions | 233.7 mm × 160.0 mm (approx) |
| Weight | ~4 kg (approx) |
| Status | Legacy industrial module often available from surplus / secondary market |
FAQ
FAQ
Q1. What is the XVME-230 module used for?
It is an intelligent counter module that performs high-speed counting, measurement, and control functions within VMEbus-based industrial systems.
Q2. What bus interface does XVME-230 use?
It uses a VMEbus interface compatible with standard VMEbus backplanes.
Q3. How many counting channels does the module support?
It supports 16 independent counting channels.
Q4. What processor does it have onboard?
The module integrates a 10 MHz 68000 CPU for on-board processing.
Q5. What types of measurements can XVME-230 perform?
It can measure frequency, period, pulse width, position, duty cycle and handle related counting tasks.
Q6. What power supply does this module require?
The board operates from +5 V DC with typical current around 4.6 A.
Q7. What are typical physical dimensions of the card?
It occupies a standard VME module form factor, about 233.7 mm × 160.0 mm.
Q8. Is XVME-230 still in current production?
No, it is generally a legacy / surplus industrial module available second-hand.
