Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | F4204 |
| System Platform | HIMA Planar F System |
| Function Type | Safety Relay Module |
| Number of Channels | 4 independent safety relay outputs |
| Contact Type | Normally Open (NO) |
| Contact Rating | Max 250 V AC / 6 A (resistive load) |
| Electrical Isolation | Channel-to-channel isolation |
| Supply Voltage | 24 V DC (range 18–30 V DC) |
| Power Consumption | Approx. 2.5 W |
| Mounting Method | Plug-in, DIN rail mountable |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Vibration Resistance | Complies with IEC 60068-2-6 |
| Shock Resistance | Complies with IEC 60068-2-27 |
| Dimensions | 120 x 25 x 90 mm |
| Weight | 0.18 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: In which safety systems is the F4204 module primarily used?
A1: It is widely used in process industry safety systems such as chemical plants, oil & gas, energy, and power generation for critical safety relay control.
Q2: What is the maximum output current supported by the F4204?
A2: Each channel supports up to 6 A (resistive load) via normally open relay contacts.
Q3: Does the module provide electrical isolation between channels?
A3: Yes, the F4204 provides full electrical isolation between channels to ensure safe and independent operation.
Q4: Is the module suitable for redundant configurations?
A4: Yes, it can be integrated into redundant safety architectures for enhanced reliability.
Q5: What is the mounting method for this module?
A5: It features a plug-in design and is DIN rail mountable, facilitating easy installation and maintenance.
Q6: Is hot swapping supported by the F4204?
A6: No, hot swapping is not supported. Power must be turned off before replacing the module.
Q7: Is the F4204 certified to international safety standards?
A7: Yes, it complies with major international safety standards, including IEC 61508 for SIL 3 certification.
Q8: What is the allowable operating temperature range?
A8: The module operates reliably in environments ranging from 0°C to +60°C.
