HIMA Z7108/3237/W/R1 Special Cable Plug

FAQ

Q1: What is HIMA Z7108/3237/W/R1?
A: It is a special cable plug designed for the HIMA F 3237 safety input module.

Q2: What module is it compatible with?
A: It is specifically designed for the HIMA F 3237 8-channel input module.

Q3: What is the main application?
A: It is used for the redundant connection of NAMUR proximity switches to the F 3237 module.

Q4: What type of sensors does it support?
A: It is intended for NAMUR proximity switches according to EN 60947-5-6.

Q5: What resistors are included in the R1 configuration?
A: The R1–R8 resistors are 390 Ω, corresponding to the eight input channels.

Q6: Is this a standalone I/O module?
A: No. It is a cable plug/interface accessory and must be used together with the compatible F 3237 input module.

Q7: What is the function of the redundant connection?
A: It provides the wiring arrangement required to connect a safety-related proximity switch redundantly to the F 3237 input circuitry.

Q8: What should be checked before replacement?
A: Verify the F 3237 module version, Z7108 connector configuration, R1 resistor arrangement and NAMUR sensor wiring before installation. HIMA documentation notes that the use of special cable plugs in the safety loop can affect the achievable SIL level depending on the connected proximity switch.

HIMA Z7108/3237/W/R1
