Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Honeywell Analytics |
| Product Number | 05701-A-0405 |
| Product Type | AC-to-DC Power Supply Unit |
| Product Series | System 57 |
| System | Honeywell System 57 / 5701 |
| Rack Capacity | 16-Way |
| Power Rating | 50 W |
| Input Voltage | 85–264 V AC, 47–440 Hz |
| DC Input Range | 110–340 V DC |
| Output Voltage | 24 V DC nominal |
| Output Tolerance | ±10% |
| Power Supply Type | Switched-mode power supply |
| Upgrade Capability | Upgradable to 100 W and up to 200 W with additional modules/subunits |
| Protection | Overload and overvoltage protection |
| Mounting | 1U high, 19-inch rack-mounted |
| Application | System 57 gas and fire detection systems |
| Operating Temperature | -25 to +55°C |
| Operating Humidity | 20–90% RH, non-condensing |
| Earthing | M5 earth stud |
| Approvals | EN 50270 |
| Dimensions | Approx. 482.6 × 44.5 × 250 mm |
| Weight | Approx. 0.96 kg |
| Origin | USA |
FAQ
FAQ
Q1: What is the Honeywell 05701-A-0405 used for?
A: The 05701-A-0405 supplies regulated DC power to Honeywell System 57 gas and fire detection equipment. It is designed for 16-way System 57 racks.
Q2: What is the power rating of the 05701-A-0405?
A: The standard power supply is rated at 50 W. The unit can be upgraded by adding additional 50 W power-supply modules.
Q3: What input voltage does the 05701-A-0405 support?
A: It accepts 85–264 V AC at 47–440 Hz. It can also operate from a 110–340 V DC input.
Q4: What output voltage does the power supply provide?
A: The unit provides a nominal 24 V DC output, with a specified tolerance of approximately ±10%.
Q5: Can the 05701-A-0405 be upgraded to a higher power rating?
A: Yes. Honeywell specifies that the 16-way power supply can be upgraded to 100 W by adding another 50 W module. A further subunit can be installed to increase the available power to 150 W or 200 W, depending on the configuration.
Q6: What protection functions are provided?
A: The power supply includes overload and overvoltage protection. The overload protection automatically recovers after the overload condition is removed.
Q7: How is the 05701-A-0405 installed?
A: It is installed as a 1U-high, 19-inch rack-mounted power supply within a Honeywell System 57 installation.
Q8: What are the dimensions and weight of the 05701-A-0405?
A: The unit is approximately 482.6 × 44.5 × 250 mm and weighs approximately 0.96 kg in the standard 16-way, 50 W configuration.
