Honeywell 10201/2/1 9910150087 Fail-safe Digital Output Module

Product FAQs (Presented in QA Format)

Q1: What is the maximum current for each output channel on the 10201/2/1 module?

A1: The maximum current for each output channel is 550 mA.

Q2: Can this module handle inductive loads like solenoids?

A2: Yes, the module can handle inductive loads like solenoids, and it includes suppression diodes on each output to protect against voltage spikes.

Q3: What is the maximum lamp load the module can support?

A3: The maximum lamp load the module can support is 120 mA (2.9 W).

Q4: Is this module tested for fail-safe applications?

A4: Yes, the module is fully tested for fail-safe applications, including the ability to de-energize and handle cross-talk between outputs.

Q5: What is the voltage drop at 500 mA for this module?

A5: The voltage drop at 500 mA is less than 2.0 Vdc.

Q6: What certifications does the Honeywell 10201/2/1 module have?

A6: The module is certified with CE, TüV, and UL approvals.

Q7: What are the power requirements for this module?

A7: The power requirements are 5 Vdc 25 mA, 24 Vdc internal 25 mA, and 24 Vdc external 70 mA (without output load).

Q8: What is the space requirement for mounting this module?

A8: The module requires 4 TE, 3 HE, or 4 HP, 3U of space.

Q9: How is this module protected from inductive load spikes?

A9: Each output channel has an integrated suppression diode to protect the module from voltage spikes caused by inductive loads.

Q10: What are the dimensions and weight of this module?

A10: The module’s dimensions are 30 x 200 x 150 mm, and it weighs 0.15 kg.
