Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 51308017-100 |
| Product Type | Analog Output Module |
| Signal Type | 4-20mA Current Output |
| Channels | 8 Channels |
| Resolution | 12-bit |
| Isolation | Channel-to-bus isolation |
| Response Time | ≤ 20 ms |
| Operating Voltage | 24 VDC nominal |
| Power Consumption | ≤ 5W |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity Range | 5% to 95% RH, non-condensing |
| Cable length | 1 m |
| Weight (kg) | 0.48 kg |
| Mounting Type | DIN Rail Mounting |
| Compliance | CE, UL, RoHS |
FAQ
FAQ
Q1: What is the primary function of the 51308017-100 module?
A1: It functions as an analog output module used to transmit 4-20mA current signals to control field devices.
Q2: How many output channels does this module support?
A2: The module supports 8 independent analog output channels.
Q3: Is the module hot-swappable during system operation?
A3: No, it is not recommended to hot-swap this module during operation to avoid system faults.
Q4: What type of wiring is recommended for signal connections?
A4: Use shielded twisted-pair cables for optimal noise immunity and signal integrity.
Q5: What is the isolation type provided by the module?
A5: It provides channel-to-bus electrical isolation to enhance safety and signal stability.
Q6: Does the module support HART communication?
A6: No, this specific model does not support HART; it only transmits analog current signals.
Q7: What is the required power supply for this module?
A7: The module requires a nominal 24 VDC power supply.
Q8: Can the module be used in harsh environmental conditions?
A8: Yes, it can operate in temperatures from 0°C to 60°C and withstand humidity up to 95% non-condensing.
