Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 621-0012 |
| Type | ASCII Communication Module |
| Communication Protocol | ASCII / Modbus selectable |
| Interface Type | RS-232 / RS-485 |
| Baud Rate | 1200 ~ 115200 bps configurable |
| Data Bits | 7 or 8 bits |
| Stop Bits | 1 or 2 bits |
| Parity | None, Odd, Even selectable |
| Power Supply | 24 V DC ±10% |
| Power Consumption | Max 3 W |
| Operating Temperature | 0°C ~ 55°C |
| Storage Temperature | -20°C ~ 70°C |
| Relative Humidity | 5% ~ 95% (non-condensing) |
| Protection Class | IP20 |
| Dimensions | 240 × 25 × 130 mm |
| Weight | 0.54 kg |
| Compatible Systems | Honeywell Experion PKS / TDC 3000 systems |
FAQ
FAQ
Q1: Which communication protocols does 621-0012 support?
Supports ASCII and Modbus protocols selectable.
Q2: What interface types are supported?
Supports RS-232 and RS-485 interfaces.
Q3: What is the baud rate range?
Baud rate configurable from 1200 to 115200 bps.
Q4: What are the dimensions and weight of the unit?
Dimensions: 240 × 25 × 130 mm; Weight: 0.54 kg.
Q5: How are data bits and stop bits configured?
Supports 7 or 8 data bits, and 1 or 2 stop bits.
Q6: What parity options are available?
Selectable: None, Odd, or Even parity.
Q7: Which systems is it compatible with?
Compatible with Honeywell Experion PKS and TDC 3000 systems.
Q8: What should be considered during installation?
Ensure proper connection of interfaces and avoid static damage and high humidity.
