Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | 8C-PAINA1 (Coated) |
| Input Type | Current (2-wire or self-powered transmitters) |
| Input Channels | 16 channels (Single Ended) |
| Voltage Rating | 24 VDC |
| Module Current Rating | 105 mA |
| Input Range | 4–20 mA (through 250 Ω) |
| A/D Converter Resolution | 16 bits |
| Input Scan Rate | 50 ms |
| Hardware Accuracy | ±0.075% of full-scale (at 23.5 °C ±2 °C), ±0.15% full-scale (0–60 °C) |
| Maximum Input Voltage | ±30 V (no damage) |
| Normal Mode Rejection Ratio | 19 dB @ 60 Hz |
| Filter Response | Single-pole RC, -3 dB @ 6.5 Hz |
| Crosstalk | -60 dB (channel-to-channel, DC to 60 Hz) |
| Galvanic Isolation | 1000 VAC RMS or ±1000 VDC |
| Isolation Technique | iCoupler (in IOM) |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 85 °C |
| Module Removal Under Power | Supported |
| Certifications | Class I, Div 2, Groups A-D, T4; Class I, Zone 2, AEx/Ex nA IIC T4 |
| Dimensions | 220 x 120 x 60 mm |
| Weight | 0.3 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of signal does the 8C-PAINA1 module accept?
A1: The 8C-PAINA1 module accepts analog current input signals in the 4–20 mA range, either from 2-wire or self-powered transmitters.
Q2: How many channels are available on this module?
A2: The module provides 16 single-ended input channels.
Q3: Is the 8C-PAINA1 suitable for redundant applications?
A3: Yes, it supports redundancy when used with compatible redundant IOTA modules (such as 8C-TAIXB1).
Q4: Can the module be removed or inserted while powered?
A4: Yes, hot-swapping is supported, allowing safe removal and insertion under power.
Q5: What is the isolation level provided for input channels?
A5: The module provides galvanic isolation up to 1000 VAC RMS or ±1000 VDC using iCoupler technology.
Q6: What accuracy can be expected from this module?
A6: The accuracy is ±0.075% of full scale at 23.5 °C and ±0.15% over the full operating range of 0 to 60 °C.
Q7: What are the physical dimensions and weight of the module?
A7: The 8C-PAINA1 module measures 220 x 120 x 60 mm and weighs 0.3 kg.
Q8: What certifications does this module carry for hazardous environments?
A8: It is certified for Class I, Division 2, Groups A, B, C, D, T4 and Class I, Zone 2, AEx/Ex nA IIC T4, suitable for use in industrial hazardous locations.
