Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 8C-SHEDA1 51307186-175 |
| Type | Header Board |
| Function | Signal interface and connection module |
| Compatible Modules | Honeywell 8C series I/O modules |
| Voltage | 24 V DC |
| Current | ≤ 1.5 A |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions (L × W × H) | 210 x 130 x 30 mm |
| Weight | 0.45 kg |
| Material | FR4 PCB, standard electronic components |
| Mounting | DIN rail or panel mounting |
| Connector Type | 2.54 mm pitch header pins |
| Certifications | CE, UL |
FAQ
FAQ
-
Q1: What is the primary function of the 8C-SHEDA1 Header Board?
A1: It serves as a connection interface for Honeywell 8C I/O modules, enabling signal routing and communication. -
Q2: Which modules are compatible with this header board?
A2: It is compatible with all Honeywell 8C series I/O modules. -
Q3: What are the operating temperature limits?
A3: The board can operate between -20°C and +70°C. -
Q4: How is the board mounted?
A4: It can be mounted on a DIN rail or directly on a panel. -
Q5: What voltage does the header board require?
A5: It requires 24 V DC for proper operation. -
Q6: What are the dimensions and weight of the board?
A6: Dimensions are 210 x 130 x 30 mm, and weight is 0.45 kg. -
Q7: Does the board have any certifications?
A7: Yes, it is CE and UL certified. -
Q8: Can the header board be used outdoors?
A8: It is designed for industrial indoor use; outdoor use may require additional protection.
