Honeywell 8C-TAIXB1 51307129-175 Series 8 Controller Analog Input IOTA

Frequently Asked Questions (FAQ)

Q1: What input modules does 8C-TAIXB1 support?
A1: It supports 8C-PAIHA1 (with HART) and 8C-PAINA1 (without HART) analog input modules.

Q2: How many channels can be handled by one IOTA?
A2: Each IOTA can handle up to 16 single-ended analog input channels.

Q3: Is redundancy supported?
A3: Yes, 8C-TAIXB1 is designed for redundant applications to enhance system availability.

Q4: What is the input signal type?
A4: It accepts 4-20 mA current signals from 2-wire or self-powered transmitters.

Q5: Does the module offer isolation between system and field?
A5: Yes, it provides galvanic isolation rated at 1000 VAC RMS or ±1000 VDC.

Q6: Is hot swapping supported?
A6: Yes, the module supports insertion and removal under power.

Q7: What are the standard dimensions and weight of the module?
A7: It measures 220 x 120 x 152.4 mm and weighs 0.3 kg.

Q8: What are the recommended operating conditions?
A8: The module operates in 0–50°C ambient temperature and 5–95% non-condensing humidity.

51307129-175 8C-TAIXB1 Analog Input IOTA Honeywell Series 8 Controller

We will use wear-resistant cartons to seal the boxes, and take photos for your confirmation before sealing. We will pack the boxes only after confirmation.

For express delivery, we will use DHL, UPS, TNT, FedEx and EMS.

Please rest assured that we have a deep cooperation with express delivery companies and can ensure that your goods are delivered to you in good condition.
