Technical Specifications
| Parameter | Description |
|---|---|
| Model | 900H03-0202 |
| Type | HC900 Digital Output Module |
| Number of Outputs | 8 channels |
| Output Type | Transistor/Relay selectable |
| Max Load Current | 0.5 A/channel (transistor) |
| Output Voltage Range | 24 VDC |
| Communication Interface | HC900 bus interface |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Electrical Isolation | 250 VAC |
| Dimensions | 137 x 35.6 x 151.7 mm |
| Weight | 0.23 kg |
| Mounting | DIN rail mount |
FAQ
FAQ
-
Q1: What types of loads does this module support?
A1: The module supports transistor outputs for low-current loads and relay outputs for high-current devices. -
Q2: What is the maximum switching frequency?
A2: The transistor output can switch up to 1 kHz, suitable for fast response applications. -
Q3: Which HC900 controllers is this module compatible with?
A3: The module is compatible with all HC900 series controllers and standard bus communication. -
Q4: Can this module operate in high-temperature environments?
A4: The operating temperature range is -20°C to 60°C. Exceeding this may affect performance. -
Q5: Does it support hot-swapping?
A5: The module does not support hot-swapping; installation or maintenance requires power off. -
Q6: Is there protection against overcurrent?
A6: The module includes overcurrent protection that automatically disconnects the output if limits are exceeded. -
Q7: Does the module require an external power supply?
A7: The module is powered through the HC900 bus and does not need an external supply. -
Q8: Can this module be used outdoors?
A8: With an IP20 rating, the module is intended for indoor use only; outdoor installation requires a protective enclosure.
