Technical Specifications
| Item | Specification |
|---|---|
| Module Type | Fiber Optic Communication Module |
| Model Number | CC-FSMX01 |
| Part Number | 51405048-175 |
| Communication Medium | Fiber Optic |
| Transmission Type | Full Duplex |
| Supported Distance | Up to 2 km (multimode fiber) |
| Interface Type | ST-type fiber connectors |
| Protocol | FTE (Fault Tolerant Ethernet) |
| Data Rate | 100 Mbps |
| Compatibility | Honeywell C300 Controller, FTE networks |
| LED Indicators | Link, Activity, Status |
| Power Supply | Supplied via control system backplane |
| Mounting Type | Chassis mount (I/O module rack) |
| Dimensions | 150 x 100 x 30 mm |
| Weight | 0.4 kg |
| Operating Temperature | 0 to +60 °C |
| Storage Temperature | -40 to +85 °C |
| Relative Humidity | 5% to 95%, non-condensing |
FAQ
FAQ
Q1: What is the function of the CC-FSMX01 module?
A1: It provides high-speed fiber optic communication for FTE-based Honeywell control systems.
Q2: What type of fiber does it support?
A2: The module supports multimode fiber for distances up to 2 km.
Q3: What kind of connectors are used?
A3: It uses ST-type connectors for fiber optic connections.
Q4: What is the maximum data transmission rate?
A4: The module supports 100 Mbps full-duplex communication.
Q5: What systems is this module compatible with?
A5: It is compatible with Honeywell C300 controllers and FTE networks.
Q6: How is the module powered?
A6: Power is provided through the system backplane, no separate power supply is needed.
Q7: Does the module support redundancy?
A7: Yes, when used in an FTE network, redundancy is supported by design.
Q8: What are the physical dimensions and weight of the CC-FSMX01?
A8: The module measures 150 x 100 x 30 mm and weighs 0.4 kg.
