Technical Specifications
| Parameter | Specification |
|---|---|
| Model | CC-PAIH51 – High-Level Analog Input with HART |
| IOTA Models | CC-TAIX51 Non-Redundant (6″) |
| CC-TAIX61 Redundant (12″) | |
| Input Type | Current (2-wire or self-powered transmitters) |
| Input Channels | 16 Channels (All Single Ended) |
| Common Mode Rejection Ratio | 70 dB (dc to 60 Hz) |
| Common Mode Voltage | -6 to +5 V peak (dc to 60 Hz) |
| A/D Converter Resolution | 16 bits |
| Input Range | 4-20 mA only (through 200 Ω) |
| Normal Mode Rejection Ratio | 19 dB at 60 Hz |
| Normal Mode Filter Response | Single-pole RC, -3 dB @ 6.5 Hz |
| Maximum Normal Mode Input | ±30 Volts |
| Crosstalk | -60 dB (dc to 60 Hz, channel-to-channel) |
| Input Scan Rate | 50 ms |
| Hardware Accuracy | ±0.075% of full-scale (23.5°C ± 2°C) |
| ±0.15% of full-scale (0°C to 60°C) | |
| Transmitter Field Power Conditioning | Protected Current Limiting Circuits for Class 1 |
| Dimensions | 63.5 x 124.46 x 307.34 mm |
| Weight | 0.299 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the input type for the Honeywell CC-PAIH51 module?
A1: The CC-PAIH51 module accepts current inputs from 2-wire or self-powered transmitters.
Q2: How many input channels does the CC-PAIH51 have?
A2: The module provides 16 input channels, all single-ended.
Q3: What is the A/D converter resolution for the CC-PAIH51?
A3: The A/D converter resolution is 16 bits.
Q4: What is the accuracy of the module?
A4: The hardware accuracy is ±0.075% of full scale at 23.5°C ± 2°C, and ±0.15% of full scale from 0°C to 60°C.
Q5: Does the CC-PAIH51 module support redundancy?
A5: Yes, the module supports redundancy with the use of the CC-TAIX61 IOTA (12″).
Q6: What is the maximum normal mode input for the CC-PAIH51?
A6: The maximum normal mode input is ±30 Volts.
Q7: What are the dimensions and weight of the CC-PAIH51 module?
A7: The module’s dimensions are 63.5 x 124.46 x 307.34 mm, and it weighs 0.299 kg.
Q8: What type of field power conditioning does the module provide?
A8: The module features individually protected current limiting circuits for Class 1, Division 2 non-incendive interfacing. No fusing is required.
