Honeywell CC-PAIM01 51405045-175 Series-C High Level Analog Input Module

Frequently Asked Questions (FAQ)

Q1: What types of temperature inputs are supported?
A1: The module supports both thermocouple types (J, K, T, E, B, S, R, R’) and RTDs (Pt100, Ni120, Cu10).

Q2: How many input channels can one module handle?
A2: Up to 64 channels, added in 16-channel increments.

Q3: Does it support open thermocouple detection (OTD)?
A3: Yes, it performs OTD and marks invalid inputs as NAN to prevent incorrect control.

Q4: What is the scan rate for input channels?
A4: The scan rate is fixed at 1 second for up to 64 channels.

Q5: Is each channel electrically isolated?
A5: Yes, all channels are fully isolated from each other and from power system ground.

Q6: What is the maximum allowable common mode voltage?
A6: The module supports up to ±250 VDC or VAC RMS CMV.

Q7: Is the module surge protected?
A7: Yes, it meets EN 61000-4-5 industrial surge protection standards.

Q8: What are the dimensions and weight of the module?
A8: The dimensions are 63.5 × 124.46 × 307.34 mm and the weight is 0.299 kg.

51405045-175 CC-PAIM01 High Level Analog Input Module Honeywell Series-C
