Honeywell CC-PDIL51 51454405-175 Series-C Digital Input Module

Frequently Asked Questions (FAQ)

Q1: How many input channels does the CC-PDIL51 support?
A1: It supports 32 channels of 24VDC digital input.

Q2: Does this module support open wire detection?
A2: No, open wire detection is not supported in this model.

Q3: Is redundancy supported?
A3: Yes, it supports redundancy using the CC-TDIL61 IOTA.

Q4: What is the isolation voltage rating?
A4: It is rated at 1000 VAC RMS between input channels and logic common.

Q5: What is the operating voltage range?
A5: The DI operating voltage range is 18 to 30 VDC.

Q6: How is the module mounted?
A6: It is vertically mounted directly into the IOTA; no separate chassis required.

Q7: What is the channel response delay?
A7: Each input has a delay of 5 ms ±20% across the filter and isolation.

Q8: What are typical applications of this module?
A8: Commonly used for discrete signal acquisition such as sensor status or push-button monitoring in process control systems.

51454405-175 CC-PDIL51 Digital Input Module Honeywell Series-C
