Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Honeywell CC-PUIO31 51454220-176 |
| Type | Universal I/O Module |
| Function | Provides flexible, configurable analog and digital input/output channels for diverse process control applications |
| Input Channels | Supports analog inputs (4–20 mA, 1–5 V), digital inputs, and pulse inputs |
| Output Channels | Supports analog outputs (4–20 mA, 1–5 V) and digital outputs |
| Number of Channels | 8 configurable I/O channels |
| Input Signal Types | Analog current, voltage, digital signals, pulse inputs |
| Output Signal Types | Analog current, voltage, digital outputs |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Power Supply Voltage | Supplied via I/O backplane |
| Power Consumption | Approx. 6 W |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5–95% RH (non-condensing) |
| Dimensions | 63.5 x 124.46 x 307.34 mm |
| Weight | 0.3 kg |
| Mounting | Mounted on Honeywell I/O base unit |
| Application | Industrial process control requiring mixed analog and digital I/O channels |
FAQ
FAQ
1. What does the Honeywell CC-PUIO31 module do?
It provides configurable analog and digital input/output channels for process control applications.
2. How many input/output channels does it support?
It supports 8 configurable I/O channels.
3. What types of input signals are supported?
Analog current, voltage, digital signals, and pulse inputs.
4. What types of outputs does it provide?
Analog current, voltage, and digital outputs.
5. Does the module provide channel isolation?
Yes, it features channel-to-channel and channel-to-ground isolation.
6. Does it require an external power source?
No, it is powered through the I/O backplane.
7. What is the operating temperature range?
0 °C to +60 °C.
8. In which applications is this module commonly used?
Used in industrial process control requiring versatile mixed analog and digital I/O functionality.
