Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | DC-TAIX61 |
| Type | Analog Input Module |
| Input Channels | 8 universal analog inputs |
| Input Signal Types | 0–20 mA, 4–20 mA, 0–10 V, ±10 V |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Sampling Rate | 10 Hz per channel |
| Isolation | Channel-to-channel and channel-to-power isolation |
| Response Time | <100 ms |
| Operating Temperature | -20°C to 70°C |
| Power Supply | 24 V DC ±10% |
| Mounting Type | DIN rail |
| Dimensions | 30 x 313 x 156 mm |
| Weight | 0.5 kg |
| Certifications | CE, UL |
FAQ
FAQ
Q1: How many input channels does the DC-TAIX61 have?
A1: 8 universal analog inputs.
Q2: What signal types are supported?
A2: 0–20 mA, 4–20 mA, 0–10 V, ±10 V.
Q3: What is the module’s resolution?
A3: 16-bit.
Q4: What is the accuracy of the inputs?
A4: ±0.1% of full scale.
Q5: What is the maximum sampling rate per channel?
A5: 10 Hz per channel.
Q6: Does the module have channel-to-channel isolation?
A6: Yes, both channel-to-channel and channel-to-power isolation.
Q7: What is the operating temperature range?
A7: -20°C to 70°C.
Q8: What certifications does this module have?
A8: CE and UL certified.
