Technical Specifications
| Parameter | Specification |
|---|---|
| Communication Ports | RS-232C ×1, RS-485 ×1 |
| Supported Protocols | MODBUS RTU (Master/Slave), ASCII (limited), Custom serial protocols |
| Baud Rate Range | 300 – 115.2 kbps |
| Port Configuration | Configurable parity, stop bits, data bits via software |
| Isolation | Optical isolation on RS-485 line |
| Maximum Connected Devices | Up to 32 devices on RS-485 bus |
| Operating Temperature | -20°C to +60°C |
| Power Supply | 24V DC (via controller backplane) |
| Mounting | DIN rail or baseplate mount (depending on controller) |
| Certifications | CE, UL, CSA, RoHS compliant |
| Dimensions | 120 × 100 × 80 mm |
| Weight | 1 kg |
FAQ
FAQ
-
Q1: What types of industrial devices can FC-DCOM-234/485 interface with?
A: It supports connectivity with flow computers, analyzers, RTUs, PLCs, and other field devices using RS-232C or RS-485 serial communication. -
Q2: Can RS-232C and RS-485 ports operate simultaneously?
A: No, only one port can be active at a time; configuration must select either RS-232C or RS-485. -
Q3: What is the maximum number of devices supported on the RS-485 bus?
A: The module supports up to 32 devices connected on the RS-485 network. -
Q4: How is the port configuration adjusted for parity, stop bits, and data bits?
A: Port parameters are configurable through the software interface provided by the controller system. -
Q5: What is the operating temperature range for reliable communication?
A: The module functions correctly in temperatures between -20°C and +60°C. -
Q6: Does the module provide electrical isolation for RS-485 communication?
A: Yes, optical isolation is included to protect the RS-485 line from voltage spikes and noise. -
Q7: Which protocols are supported for legacy system integration?
A: MODBUS RTU (Master/Slave), limited ASCII, and custom serial protocols can be used to interface with legacy systems. -
Q8: How is the module physically mounted within the system?
A: It can be mounted on a DIN rail or baseplate depending on the controller setup.
