Technical Specifications
| Parameter | Specification |
|---|---|
| Model | FC-TSFIRE-1624 |
| Function | Field Termination Assembly (FTA) for Honeywell Safety Manager systems |
| Input Channels | 16 digital fire detector inputs |
| Operating Voltage | 24 VDC |
| Current Consumption | No load: 11 mA Typical with EOL resistor: 70 mA Maximum: 570 mA |
| Channel Resistance | 680 Ω ±5% |
| Shorted Current | Approx. 35 mA |
| Relay Voltage | 17–39 VDC |
| Relay Current | Typical 8.5 mA at 24 VDC |
| Temperature Range | -40°C to +70°C |
| Humidity | 0–95% RH, non-condensing |
| Enclosure Rating | NEMA 1, IP30 |
| Mounting | DIN EN rail snap-in |
| Termination | Screw terminals |
| Dimensions | 170 × 70 × 64 mm |
| Weight | 0.8 kg |
FAQ
FAQ
-
What type of fire detectors can the FC-TSFIRE-1624 interface with?
The module supports conventional digital fire detectors compatible with Honeywell Safety Manager systems. -
How is the FC-TSFIRE-1624 powered and what is its current requirement?
It operates on 24 VDC, with typical current consumption of 70 mA when connected with end-of-line resistors. -
What are the environmental operating limits of this module?
The device functions reliably between -40°C to +70°C and 0–95% relative humidity, non-condensing. -
How are the field connections terminated?
Field wiring and power supply connections are secured via screw terminals. -
Can this module handle short circuits or faults in detector lines?
Yes, it is designed to detect shorted circuits with an approximate shorted current of 35 mA. -
What are the physical dimensions and weight of the FC-TSFIRE-1624?
The module measures 170 × 70 × 64 mm and weighs 0.8 kg. -
Is the FC-TSFIRE-1624 suitable for hazardous locations?
It is designed for industrial and commercial environments, including Class I, Division 2 areas. -
How does the relay interface function within the system?
The module includes a relay output with 17–39 VDC voltage range and typical current of 8.5 mA at 24 VDC to trigger external devices.
