Technical Specifications
| Parameter | Specification |
|---|---|
| Output Channels | 8 |
| Output Type | Relay contacts (potential-free) |
| Supply Voltage | 24 VDC |
| Maximum Output Voltage | 250 VAC, 60 Hz |
| Maximum Output Current | 5 A |
| Safety Integrity Level (SIL) | SIL3 (IEC 61508) |
| Connection Type | Field wiring via terminal blocks |
| Mounting Type | DIN rail |
| Dimensions | 300 × 70 × 60 mm |
| Weight | 0.53 kg |
| Operating Environment | Industrial process control systems |
| Applications | Valves, motors, and other actuators |
FAQ
FAQ
-
Q1: What type of relays does the FC-TSRO-0824 use and are they rated for heavy industrial loads?
A1: The module uses potential-free relay contacts capable of switching up to 250 VAC and 5 A, suitable for typical industrial actuators and devices. -
Q2: How is the module mounted and connected in the field?
A2: It is DIN rail mounted and connects to field devices through terminal blocks for secure wiring. -
Q3: Can the FC-TSRO-0824 interface with multiple Honeywell safety systems simultaneously?
A3: Yes, it is compatible with Honeywell Safety Manager and other digital output systems, allowing multiple connections. -
Q4: What safety integrity level (SIL) does this module achieve?
A4: The FC-TSRO-0824 is certified to SIL3 under IEC 61508 standards. -
Q5: Is the module suitable for high-frequency switching applications?
A5: It is designed for standard industrial switching rates; high-frequency switching should be evaluated based on relay contact ratings. -
Q6: What is the operating voltage range for the supply input?
A6: The supply voltage is 24 VDC; deviations outside this range can affect relay operation. -
Q7: Are there any specific environmental conditions for optimal operation?
A7: The module is intended for industrial environments with standard temperature and humidity conditions; avoid corrosive or explosive atmospheres. -
Q8: Can multiple FC-TSRO-0824 modules be cascaded for expanded output capacity?
A8: Yes, multiple modules can be used in parallel to expand the number of digital outputs.
