Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | FS-SDO-04110 / FC-SDO-04110 |
| Approvals | CE, TUV, UL, CSA |
| Power Supply Voltage | 110 V DC, -15% to +25% |
| Power Requirements | 5 V DC, 25 mA; 110 V DC internal 10 mA; 110 V DC external 20 mA (no load) |
| Number of Output Channels | 4 |
| Output Type | 110 V DC solid-state source, short-circuit proof |
| Maximum Channel Current | 325 mA |
| Maximum Load per Channel | 55 mA (6 W) |
| Maximum Load Capacitance | 1 µF |
| Voltage Drop at 300 mA | < 2.5 V DC |
| Off-state Leakage Current | < 0.1 mA |
| Watchdog Input Current | 5 mA |
| Space Requirement | 4 TE, 3 HE (= 4 HP, 3U) |
| Dimensions | 20.32 x 133.35 x 156 mm |
| Weight | 0.7 kg |
FAQ
FAQ
Q1: How many output channels does the module support?
A1: The module provides 4 safe digital output channels.
Q2: What is the output voltage and maximum current per channel?
A2: Each channel outputs 110 V DC with a maximum current of 325 mA.
Q3: What is the input power voltage range?
A3: The input power voltage range is 110 V DC with tolerance from -15% to +25%.
Q4: Does the module have short-circuit protection?
A4: Yes, the outputs are solid-state source type and short-circuit proof.
Q5: What are the dimensions and weight of the module?
A5: The module measures 20.32 x 133.35 x 156 mm and weighs approximately 0.7 kg.
Q6: Which certifications does the module have?
A6: The module is certified with CE, TUV, UL, and CSA.
Q7: What is the space requirement for installation?
A7: The installation requires 4 TE, 3 HE (equivalent to 4 HP, 3U) of rack space.
Q8: What is the voltage drop under load?
A8: The voltage drop is less than 2.5 V DC at 300 mA load.
