Technical Specifications
| Parameter | Specification |
|---|---|
| Model | FS-TSAI-1620M |
| Number of Input Channels | 16 (2 groups of 8 with common 0 V) |
| Input Signal Range | 0–25 mA |
| Input Resistance | 250 Ω ±1% |
| Output to SAI-1620m Module | 0–4 V DC |
| Output Accuracy | ±0.1% |
| Power Supply Requirement | 30 V DC external, 3 mA (excluding loop loads) |
| Output to Passive Transmitters | Output resistance 270 Ω ±5%, ignition current <120 mA @30 V DC |
| Fuse Rating | 315 mA slow-blow (5×20 mm) |
| Dimensions (L×W×H) | 210 × 70 × 60 mm (8.26 × 2.76 × 2.36 in) |
| Weight | 0.2 kg |
| Mounting Rail Type | DIN EN TS32 / TS35 × 7.5 |
| Terminal Type | Screw terminal, max 2.5 mm² wire, 0.5 Nm tightening torque |
| Certifications | CE, TUV, UL, CSA, FM |
| Hazardous Area Compliance | Class I, Division 2 |
FAQ
FAQ
Q1: How many input channels does the FS-TSAI-1620M module support?
A1: The module supports 16 analog input channels, divided into two groups of 8.
Q2: What kind of input signals can the module process?
A2: It handles 0–25 mA analog current input, typically 0–20 mA or 4–20 mA.
Q3: Is the module suitable for hazardous areas?
A3: Yes, it complies with Class I, Division 2 non-incendive field circuits.
Q4: What is the power supply requirement for the module?
A4: It requires 30 VDC external supply with 3 mA current (excluding loop loads).
Q5: What protection is available for input channels?
A5: Each group of 8 channels is protected by a 315 mA slow-blow fuse.
Q6: Can it power passive transmitters directly?
A6: Yes, it includes current-limited output with a 270 Ω resistor per channel.
Q7: How is it mounted and connected?
A7: It uses DIN EN rail mounting and screw terminals for field connections.
Q8: What is the accuracy of the module’s analog signal conversion?
A8: The conversion accuracy is ±0.1%.
