Technical Specifications
| Parameter | Description |
|---|---|
| Model | MU-PAIH03 51304754-100 |
| Product Type | High Level Analog Input Processor |
| Input Channels | 16 analog input channels |
| Input Signal Types | 0-20 mA, 4-20 mA, 0-5 V, 1-5 V |
| Accuracy | ±0.1% of full scale |
| Resolution | 16-bit |
| Isolation | Channel-to-channel and channel-to-power |
| Power Supply | 24V DC |
| Operating Temperature | 0℃ ~ 60℃ |
| Storage Temperature | -40℃ ~ 85℃ |
| Relative Humidity | 5% ~ 95%, non-condensing |
| Dimensions | 86 x 32 x 160 mm |
| Weight | 0.6 kg |
| Mounting | DIN rail mounting |
| Communication | Supports redundancy and hot swap |
FAQ
Frequently Asked Questions (FAQ)
Q1: What types of analog input signals are supported by the MU-PAIH03?
A1: It supports 0-20 mA, 4-20 mA, 0-5 V, and 1-5 V high-level analog input signals.
Q2: How many input channels does this module have?
A2: The MU-PAIH03 provides 16 independent analog input channels.
Q3: Is there isolation between input channels?
A3: Each channel is isolated from others, and all channels are isolated from the power supply for enhanced anti-interference capability.
Q4: What are the accuracy and resolution of the module?
A4: The accuracy is ±0.1% of full scale, and the resolution is 16 bits.
Q5: What is the operating temperature range?
A5: The operating temperature range is 0℃ to 60℃; storage temperature is -40℃ to 85℃.
Q6: How is the module mounted?
A6: It supports DIN rail mounting for integration into standard control cabinets.
Q7: Does it support communication redundancy and hot swap?
A7: The module supports system redundancy and online hot swap for easy maintenance and replacement.
Q8: What are the dimensions and weight of the product?
A8: The dimensions are 86 x 32 x 160 mm, and the weight is 0.6 kg.
