Technical Specifications
| Model | Honeywell SDW-550EC |
|---|---|
| Product Name | Ethernet Switch |
| Dimensions | 135 x 50 x 110 mm |
| Weight | 0.65 kg |
| Ports | 5 x 10/100/1000Base-T |
| Power Supply | 12-48V DC |
| Operating Temperature | -40°C to +75°C |
| Protocol Support | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Switching Capacity | 10 Gbps |
| Forwarding Rate | 7.44 Mpps |
| Redundancy | Support for STP/RSTP |
| Mounting Type | DIN Rail |
FAQ
FAQ
-
What is the number of ports on the Honeywell SDW-550EC Ethernet switch?
The switch has 5 x 10/100/1000Base-T ports. -
What is the supported power supply range for the Honeywell SDW-550EC?
The supported power supply range is 12-48V DC. -
What is the operating temperature range for this Ethernet switch?
The operating temperature range is -40°C to +75°C. -
Which protocols are supported by the Honeywell SDW-550EC Ethernet switch?
The switch supports IEEE 802.3, IEEE 802.3u, and IEEE 802.3x. -
What is the switching capacity of the Honeywell SDW-550EC?
The switching capacity is 10 Gbps. -
What is the forwarding rate of the Honeywell SDW-550EC?
The forwarding rate is 7.44 million packets per second (Mpps). -
Does the Honeywell SDW-550EC support redundancy?
Yes, the switch supports redundancy with STP/RSTP protocols. -
What type of mounting does the Honeywell SDW-550EC use?
The switch uses DIN Rail mounting.
