Technical Specifications
| Parameter | Specification |
|---|---|
| Module Name | TC-PMFO01 |
| Function | ControlNet Fiber Module |
| Communication Interface | ControlNet Fiber-Optic |
| Media Type | Fiber optic (multimode) |
| Cable Length Support | Up to 2 km (with appropriate repeaters) |
| Slot Occupancy | Single-wide module |
| Interface Redundancy | Supports single and dual media |
| Installation Type | CIOM-A Series A chassis |
| Electrical Isolation | Fiber provides galvanic isolation |
| Mounting | Panel mount via chassis |
| Environmental Compliance | – Operating: 0 to 60°C – Storage: -40 to 85°C |
| Humidity | 5–95% RH (non-condensing) |
| Vibration | 10 to 60 Hz, 0.5 g max |
| Shock | 5 g, 30 ms max |
| Dimensions | 94 x 94 x 87 mm |
| Weight | 0.139 kg |
FAQ
FAQ
Q1: What is the main function of the TC-PMFO01 module?
A1: The TC-PMFO01 module enables fiber-optic ControlNet communication between the C200E controller and remote I/O modules in Honeywell’s Experion system.
Q2: Does the TC-PMFO01 module support redundancy?
A2: Yes, it supports both single and dual media configurations, allowing for network redundancy.
Q3: Which platforms is the TC-PMFO01 compatible with?
A3: It is designed for use with the Experion PKS platform, particularly in C200/C200E Series A chassis-based architectures.
Q4: What is the maximum supported communication distance?
A4: With proper fiber optic cables and repeaters, the module supports communication distances up to 2 kilometers.
Q5: Is the TC-PMFO01 hot-swappable?
A5: Hot-swapping is allowed in non-hazardous locations but is strictly prohibited in Class I, Division 2 hazardous areas.
Q6: How many chassis slots does the TC-PMFO01 occupy?
A6: It is a single-width module and occupies one slot in the Series A chassis.
Q7: Does the module provide electrical isolation?
A7: Yes, electrical isolation is achieved through the use of fiber optic communication, enhancing system safety.
Q8: What are the typical applications for this module?
A8: The TC-PMFO01 is commonly used in industrial automation environments such as chemical processing, oil & gas, power generation, and other applications requiring reliable remote I/O communication.
