Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Analog Output Module |
| Output Channels | 8 channels |
| Output Signal Range | 4–20 mA or 0–10 V |
| Isolation | Non-isolated |
| Output Resolution | 12-bit |
| Output Accuracy | ±0.1% of full scale |
| Load Resistance | 0 to 600 Ω (Current mode) >1 kΩ (Voltage mode) |
| Update Rate | 10 ms typical |
| Power Supply | 24 VDC nominal |
| Power Consumption | 4.5 W typical |
| Operating Temperature | 0 to 60°C |
| Storage Temperature | -40 to 85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Installation | DIN rail mounting |
| Dimensions (W×H×D) | 114 × 50 × 120 mm |
| Weight | 0.4 kg |
FAQ
FAQ
Q1: What is the primary function of the TK-OAV081 module?
A1: The TK-OAV081 is designed to provide 8 channels of analog output, supporting both current and voltage signal types.
Q2: Is the TK-OAV081 module isolated between channels?
A2: No, this module provides non-isolated outputs.
Q3: What kind of signals does the TK-OAV081 support?
A3: It supports 4–20 mA current signals and 0–10 V voltage signals for each output channel.
Q4: What is the accuracy of the analog outputs?
A4: The module offers an accuracy of ±0.1% of full scale.
Q5: What is the load capacity for current and voltage modes?
A5: For current mode, the load range is 0 to 600 Ω; for voltage mode, it must be higher than 1 kΩ.
Q6: What is the module’s update rate?
A6: The typical update rate for all channels is 10 milliseconds.
Q7: Can this module be used in harsh environments?
A7: Yes, it operates from 0 to 60°C and can be stored at -40 to 85°C with up to 95% non-condensing humidity.
Q8: What is the recommended mounting method for the TK-OAV081?
A8: It is designed for DIN rail mounting in control panels.
