Technical Specifications
| Item | Specification |
|---|---|
| Model | Schneider 140DDO35300C |
| Type | DC Discrete Output Module |
| Product Category | PLC I/O Module |
| Product Family | Modicon Quantum automation platform |
| Function | Provides discrete DC outputs for controlling field devices |
| Number of Output Channels | 3 outputs |
| Output Voltage Range | 10–60 V DC |
| Output Logic | Positive logic (sourcing) |
| Maximum Load Current | 3 A per output |
| Total Load Current | 3 A (shared across outputs) |
| Output Protection | Short-circuit and overload protection |
| Status Indication | LED indicators for each output channel |
| Isolation | Electrical isolation between channels and backplane |
| Mounting Method | Rack or DIN rail via compatible Quantum base |
| Field Wiring Connection | Screw terminal connectors |
| Operating Temperature Range | 0 °C to +60 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Protection Rating | IP20 |
| Housing Material | Industrial-grade plastic and metal contacts |
| Application Environment | Industrial automation and machine control |
| Dimensions | Approx. 47 mm × 35 mm × 120 mm |
| Weight | Approximately 0.15 kg |
FAQ
FAQ
Q1: What is the primary function of the Schneider 140DDO35300C module?
It provides three discrete DC output channels to control field devices such as relays, solenoids, indicators, and other loads in industrial automation systems.
Q2: How many output channels does the 140DDO35300C have?
It has three DC discrete output channels.
Q3: What output voltage range does this module support?
The module supports an output voltage range of 10–60 V DC.
Q4: What is the maximum current per output?
Each output channel can handle up to 3 A of load current.
Q5: What type of logic does this output module use?
It uses positive (sourcing) logic, meaning the module sources current to the load when the output is active.
Q6: Does the module provide status indication?
Yes, it includes LED indicators for each output channel to show whether the outputs are active.
Q7: Is this module suitable for industrial environments?
Yes, it is designed for use in industrial automation and machine control cabinets within its operating temperature range.
Q8: What are the physical dimensions and weight of the 140DDO35300C?
The module measures approximately 47 mm × 35 mm × 120 mm and weighs about 0.15 kg.
