Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | ICS Triplex |
| Product Number | T8111 |
| Product Type | Trusted TMR Processor |
| Product Series | Trusted TMR |
| Function | Main processing, control and monitoring module |
| Architecture | Triple Modular Redundancy (TMR), fault-tolerant 3-2-0 operation |
| Safety Architecture | Hardware Implemented Fault Tolerance (HIFT) |
| Backplane Supply | 20–32 VDC |
| Power Dissipation | 30 W |
| Module Location | T8100 Processor Slot |
| Serial Ports | 3 × RS-422/RS-485 rear serial ports |
| Diagnostic Port | 1 × RS-232 |
| Time Synchronization | 1 × IRIG-B002, 1 × IRIG-B122 |
| Relays | 1 × Fault Relay, 1 × Fail Relay; 0.5 A @ 24 VDC |
| Communication Protocol | Modbus RTU |
| Baud Rate | 9,600–115,200 baud |
| Maximum Application Size | 960 KB |
| SOE Buffer | 1,000 events |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -25 to 70 °C |
| Relative Humidity | 10–95%, non-condensing |
| Dimensions | 266 × 93 × 303 mm (H × W × D) |
| Weight | Approx. 1.89 kg |
| Origin | USA |
FAQ
FAQ
Q1: What is the ICS Triplex T8111?
The T8111 is a Trusted TMR Processor used as the main processing component of an ICS Triplex Trusted safety control system.
Q2: What is the main function of the T8111?
It provides overall system control and monitoring while processing input and output data exchanged through the Trusted TMR Inter-Module Bus.
Q3: What redundancy architecture does the T8111 use?
It uses Triple Modular Redundancy (TMR) with fault-tolerant 3-2-0 operation and a Hardware Implemented Fault Tolerance architecture.
Q4: What power supply does the T8111 require?
The backplane supply is 20–32 VDC, with a specified power dissipation of approximately 30 W.
Q5: What communication interfaces are available?
The T8111 provides three rear RS-422/RS-485 serial ports, one RS-232 diagnostic port, and two IRIG-B time-synchronization interfaces.
Q6: Does the T8111 support Modbus?
Yes. The rear serial ports support Modbus RTU, with baud rates from 9,600 to 115,200 baud.
Q7: What are the dimensions and weight of the T8111?
The module measures approximately 266 × 93 × 303 mm and weighs approximately 1.89 kg.
Q8: Where is the T8111 installed?
It is installed in a T8100 Processor Slot and is used as the main processor for Trusted TMR safety control systems.
