Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | ICS Triplex |
| Product Number | T8151 |
| Product Type | Trusted Communications Interface Module |
| Product Series | Trusted TMR |
| Function | Provides communication services between the Trusted TMR controller and external systems, reducing communication loading on the main processor |
| Power Supply | Dual redundant 24 V DC |
| Supply Range | 20–32 V DC |
| Power Dissipation | Approx. 10 W |
| Ethernet | 2 × 10/100Base-T |
| Serial Ports | 4 × isolated serial ports; RS-232/RS-422/RS-485 depending on port |
| Diagnostic Port | 1 × RS-232 |
| Communication Protocols | Modbus RTU, Open Modbus TCP, Trusted Peer-to-Peer, Trusted Enhanced Peer-to-Peer, ICS2000 and CP2000 |
| SOE Buffer | Up to 4,000 events |
| Installation | T8100 / T8300 I/O module slot |
| Operating Temperature | 0 to +60 °C |
| Dimensions | 266 × 31 × 303 mm (H × W × D) |
| Weight | Approx. 1.13 kg |
| Origin | USA |
FAQ
FAQ
Q1: What is the ICS Triplex T8151?
It is a Trusted Communications Interface Module used in the ICS Triplex Trusted TMR safety control system.
Q2: What is the main function of the T8151?
It handles external communication services and reduces the communication workload placed on the Trusted TMR processor.
Q3: What communication interfaces does it provide?
The module provides two 10/100Base-T Ethernet ports, four isolated serial ports and a front diagnostic RS-232 port.
Q4: Which communication protocols are supported?
Supported protocols include Modbus RTU, Open Modbus TCP, Trusted Peer-to-Peer, Trusted Enhanced Peer-to-Peer, ICS2000 and CP2000.
Q5: What power supply does the T8151 require?
It uses dual redundant 24 V DC power supplied through the Trusted chassis backplane, with a specified range of 20–32 V DC.
Q6: Where is the T8151 installed?
It is installed in a single-width module slot in compatible Trusted T8100 or T8300 controller/expander chassis.
Q7: What are the dimensions and weight of the T8151?
The module is approximately 266 × 31 × 303 mm and weighs about 1.13 kg.
Q8: What applications is the T8151 suitable for?
It is used where a Trusted TMR safety controller needs reliable communication with engineering workstations, other Trusted systems, DCS/PLC systems and third-party equipment.
