Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 3601TN |
| Output Type | Digital Output (115 VAC) |
| Output Channels | 16 |
| Output Type Isolation | Opto-Isolated, Non-Commoned |
| Architecture | Triple Modular Redundant (TMR) |
| Output Circuit | Quad Voter (2-out-of-3 logic for signal safety) |
| Diagnostics | Output Voter Diagnostic (OVD), loopback testing |
| Hot-Swap Capability | Yes (supports online module repair) |
| Field Termination | Via external termination panel or fanned-out cable |
| Safety Certification | Certified for Nuclear 1E and Marine Environments |
| Dimensions (W x H x D) | 200 x 150 x 50 mm |
| Weight | 1.2 kg |
FAQ
FAQ
Q1: Does the 3601TN module support hot swapping?
A1: Yes, the 3601TN module supports hot-swapping and online replacement without disrupting the system.
Q2: What kind of fault-tolerant architecture does it use?
A2: It utilizes Triple Modular Redundant (TMR) architecture to ensure continuous and safe operation under fault conditions.
Q3: How many output channels are available per module?
A3: The module provides 16 independent digital output channels with opto-isolation.
Q4: What is the output type? Can it handle AC loads?
A4: The output type is 115 VAC digital output. It supports AC loads with opto-isolated circuits.
Q5: Are diagnostic functions supported?
A5: Yes, it includes Output Voter Diagnostics (OVD) and loopback checking to ensure output signal integrity.
Q6: Is the module certified for use in nuclear or marine environments?
A6: Yes, the 3601TN is certified for both Nuclear 1E applications and marine environments.
Q7: What termination options are available for field wiring?
A7: The module supports external termination panels (ETP) and fanned-out cable assemblies for field wiring.
Q8: What are the physical dimensions and weight of the module?
A8: The module measures 200 x 150 x 50 mm and weighs 1.2 kg.
