Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 3636T |
| Type | Non-triplicated, Relay Output |
| Output Points | 32, non-commoned |
| Output Contact | Normally Open |
| Voltage Range | Up to 125 VAC/VDC |
| Maximum Load Current | 2 A per point |
| Minimum Permissible Load | 10 mA @ 5 VDC |
| Maximum Switching Power | 2000 VA / 150 W |
| Point Isolation | 1900 VDC |
| Fuses | 1 per output (2.5 A fast-acting) |
| Diagnostic Indicators | Output Status per point; PASS, FAULT, ACTIVE |
| Dimensions | 490 x 453 x 68 mm |
| Weight | 2 kg |
FAQ
FAQ
Q1: What type of output contact does the 3636T module provide?
A1: The 3636T module provides normally open relay contacts.
Q2: How many output points does the 3636T support?
A2: The module supports 32 non-commoned output points.
Q3: What is the maximum voltage and current per output point of the 3636T?
A3: Each output point supports up to 125 VAC/VDC and up to 2 A.
Q4: What is the minimum load requirement for the 3636T?
A4: Minimum load per output point is 10 mA @ 5 VDC.
Q5: Does the 3636T have diagnostic features?
A5: Yes. Each output point has a status indicator, and the module provides PASS, FAULT, and ACTIVE status indicators.
Q6: What is the isolation rating of the 3636T module?
A6: The point-to-point isolation voltage is 1900 VDC.
Q7: What are the dimensions and weight of the 3636T?
A7: Dimensions are 490 x 453 x 68 mm, and the weight is approximately 2 kg.
Q8: Does the 3636T support hot-spare operation?
A8: Yes, it supports hot-spare modules.
