Technical Specifications
| Item | Specification |
|---|---|
| Model | 3721 |
| Product Type | Analog Input Module |
| Number of Channels | 16 channels |
| Input Type | Voltage (±10 V DC) / Current (4–20 mA) |
| Resolution | 16-bit |
| Accuracy | ±0.1% of reading ± LSB |
| Input Resistance | ≥10 MΩ (voltage), 250 Ω (current) |
| Isolation Voltage | 1500 V (channel-to-channel and channel-to-system) |
| Redundancy | Supports hot-swap and redundant configuration |
| Mounting Method | Slot-in, DIN rail |
| Operating Temp | 0°C to 60°C |
| Storage Temp | -40°C to 85°C |
| Dimensions | 185 x 135 x 45 mm |
| Weight | 1.36 kg |
FAQ
FAQ
Q1: How many analog input channels does the Triconex 3721 have?
It has 16 analog input channels.
Q2: What types of input signals are supported?
It supports ±10 V DC voltage input and 4–20 mA current input.
Q3: Does the module support redundancy?
Yes, it supports hot-swapping and redundant architecture.
Q4: What is the input resistance per channel?
≥10 MΩ for voltage input and 250 Ω for current input.
Q5: What is the resolution of the module?
The module offers 16-bit resolution.
Q6: Is there input isolation between channels?
Yes, 1500 V isolation between channels and from channel to system.
Q7: What is the operating temperature range?
It operates from 0°C to 60°C.
Q8: What are the dimensions and weight of the module?
The dimensions are 185 x 135 x 45 mm, and the weight is approx. 1.36 kg.
