Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Triconex 9761-210F |
| Type | 16-Point Current Input Module |
| Input Signal | 0–5 VDC, -5 to +5 VDC analog inputs |
| Conversion Method | 250-ohm precision resistor for current-to-voltage |
| Input Points | 16 |
| Output Terminals | 16 (+) power output, 16 (-) current input |
| Series Resistor | 180-ohm in positive terminal |
| Power Supply | Redundant 24 VDC with diode ORing |
| System Compatibility | Tricon v9–v10 safety and control systems |
| Dimensions | 114.3 × 127 × 107.95 mm |
| Weight | 0.85 kg |
| Mounting | Rack-mounted |
| Operating Temperature | 0–60 °C |
| Storage Temperature | -40–85 °C |
| Humidity | 5–95% non-condensing |
FAQ
FAQ
-
Q1: What types of signals can the 9761-210F module accept?
A1: It can accept 0–5 VDC and -5 to +5 VDC analog input signals. -
Q2: How is current converted to voltage in this module?
A2: Each input point uses a 250-ohm precision resistor to convert current signals into voltage. -
Q3: How many input points are supported by the 9761-210F?
A3: The module supports 16 individual current input points. -
Q4: What are the power supply requirements for this module?
A4: It requires a redundant 24 VDC power supply with diode ORing for reliability. -
Q5: Can the 9761-210F module interface with Tricon v10 systems?
A5: Yes, it is compatible with both Tricon v9 and v10 systems. -
Q6: What is the purpose of the 180-ohm series resistor in the module?
A6: The 180-ohm resistor limits current at the positive terminals to protect connected devices. -
Q7: What are the environmental operating conditions for the 9761-210F?
A7: Operating temperature is 0–60 °C with 5–95% non-condensing humidity. -
Q8: What are the module’s physical dimensions and weight?
A8: Dimensions are 114.3 × 127 × 107.95 mm, and weight is 0.85 kg.
