Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Triconex 9853-610 |
| Type | Analog Output Terminal Board |
| Number of Channels | 8 analog output channels |
| Output Signal Range | 4–20 mA current or 1–5 V voltage |
| Resolution | 16-bit DAC resolution |
| Accuracy | ±0.1% of full scale |
| Output Load | Up to 600 Ω for current output |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Power Supply Voltage | Supplied via Triconex backplane |
| Power Consumption | Approx. 4 W |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Humidity | 5–95% RH (non-condensing) |
| Dimensions | 150 x 118 x 83 mm |
| Weight | 0.4 kg |
| Mounting | Rack-mounted on Triconex chassis |
| Application | Industrial process control and monitoring output signals |
FAQ
FAQ
1. What is the function of the Triconex 9853-610?
It provides precise analog output signals for industrial control systems.
2. How many output channels does it support?
It supports 8 analog output channels.
3. What output signal ranges are available?
4–20 mA current and 1–5 V voltage outputs.
4. What is the resolution of the outputs?
16-bit DAC resolution for accurate control.
5. Does it provide isolation between channels?
Yes, it has channel-to-channel and channel-to-ground isolation.
6. What is the typical power consumption?
Approximately 4 W.
7. What is the operating temperature range?
0 °C to +60 °C.
8. In what applications is this terminal board used?
Used in industrial process control for analog output signal generation and monitoring.
