Technical Specifications
| Item | Specification |
|---|---|
| Model | Triconex 9863-710 |
| Type | Analog Output Panel |
| Module Type | Multi-channel analog output module |
| Number of Output Channels | 16 analog output channels |
| Output Signal Type | Configurable 4–20 mA or 0–20 mA |
| Resolution | 16-bit |
| Accuracy | ±0.1% full scale |
| Isolation | Channel isolation / module isolation |
| Response Time | ≤ 10 ms |
| Supply Voltage | 24 V DC |
| Current Consumption | Approx. 300 mA |
| Communication Interface | Triconex bus interface |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | -40 °C to +85 °C |
| Dimensions | 220 × 150 × 60 mm |
| Weight | 1.5 kg |
| Mounting | Slot-mounted module |
FAQ
FAQ
Q1: What is the main application of this analog output panel?
A1: Used in Triconex systems to convert controller signals into analog outputs to drive field control devices.
Q2: How many output channels does the module have?
A2: 16 analog output channels.
Q3: What types of output signals are supported?
A3: Configurable 4–20 mA or 0–20 mA analog signals.
Q4: What is the module resolution and accuracy?
A4: 16-bit resolution, ±0.1% full scale accuracy.
Q5: Does it support channel isolation?
A5: Yes, supports channel isolation and module isolation.
Q6: What is the operating temperature range?
A6: 0 °C to +60 °C.
Q7: What are the dimensions and weight of the module?
A7: Dimensions 220 × 150 × 60 mm, weight approx. 1.5 kg.
Q8: What is the mounting method?
A8: Slot-mounted module, suitable for Triconex control racks.
