Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Ovation 1C31025G05 |
| Type | Analog Input Module |
| System Compatibility | Ovation Distributed Control System |
| Function | Acquires and transmits analog signals from field devices |
| Power Supply Voltage | 24 V DC nominal |
| Power Consumption | Approx. 6 W |
| Input Type | Analog voltage/current signals |
| Signal Range | 0–10 V, 0–20 mA, 4–20 mA |
| Number of Channels | 16 analog input channels |
| Resolution | 12-bit or higher |
| Input Impedance | >100 kΩ for voltage inputs |
| Communication Interface | Ovation system bus |
| Isolation | Channel-to-bus galvanic isolation |
| Diagnostic Functions | Channel monitoring, fault detection, signal validation |
| Redundancy Support | Supported through system configuration |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% RH, non-condensing |
| Protection Class | IP20 |
| Compliance Standards | IEC, CE, and ANSI industrial standards |
| Dimensions | 41 × 159 × 108 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: What is the main function of the Ovation 1C31025G05 module?
A1: The 1C31025G05 is an analog input module that acquires analog signals from field devices and transmits them to the Ovation Distributed Control System for processing.
Q2: How many input channels does the 1C31025G05 support?
A2: The module provides 16 analog input channels for signal acquisition.
Q3: What types of signals can the 1C31025G05 handle?
A3: It supports voltage signals (0–10 V) and current signals (0–20 mA, 4–20 mA).
Q4: Does the 1C31025G05 provide galvanic isolation?
A4: Yes, each input channel is isolated from the system bus to ensure signal integrity.
Q5: What diagnostic functions are included in the 1C31025G05?
A5: The module includes channel monitoring, fault detection, and signal validation diagnostics.
Q6: Can the 1C31025G05 be used in redundant configurations?
A6: Yes, redundancy is supported through the Ovation system setup for increased reliability.
Q7: What communication interface does the 1C31025G05 use?
A7: It communicates via the Ovation system bus for integration with other modules in the control system.
Q8: What are the operating environmental conditions for the 1C31025G05?
A8: The module operates effectively between 0°C and +60°C with relative humidity from 5% to 95%, non-condensing.
