Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Ovation 1C31036H03 |
| Type | Power Supply Module |
| System Compatibility | Ovation Distributed Control System |
| Function | Provides reliable DC power to Ovation I/O and control modules |
| Input Voltage | 100–240 V AC, 50/60 Hz |
| Output Voltage | 24 V DC nominal |
| Output Current Capacity | Up to 5 A |
| Power Regulation | ±1% |
| Ripple and Noise | <50 mV peak-to-peak |
| Efficiency | >85% |
| Protection Features | Over-voltage, over-current, short-circuit protection |
| Communication Interface | Status signaling to Ovation system |
| Redundancy Support | Supported through system configuration |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% RH, non-condensing |
| Protection Class | IP20 |
| Compliance Standards | IEC, CE, and ANSI industrial standards |
| Dimensions | 41 × 159 × 108 mm |
| Weight | 0.6 kg |
FAQ
FAQ
Q1: What is the main function of the Ovation 1C31036H03 module?
A1: The 1C31036H03 provides stable 24 V DC power to Ovation I/O and control modules to ensure reliable system operation.
Q2: What input voltage range does the 1C31036H03 support?
A2: It supports 100–240 V AC at 50/60 Hz input voltage.
Q3: What is the maximum output current of the module?
A3: The module can supply up to 5 A of DC output current.
Q4: Does the 1C31036H03 include protection features?
A4: Yes, it features over-voltage, over-current, and short-circuit protection.
Q5: Can the 1C31036H03 be used in redundant configurations?
A5: Yes, redundancy is supported through the Ovation system configuration for critical applications.
Q6: How accurate is the output voltage?
A6: The output voltage is regulated within ±1% for precise operation of connected modules.
Q7: What is the efficiency of the 1C31036H03?
A7: The module operates with an efficiency greater than 85%.
Q8: What are the operating environmental conditions for the module?
A8: The module functions effectively between 0°C and +60°C with 5%–95% relative humidity, non-condensing.
