Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Analog Output Module |
| Output Channels | 8 channels |
| Output Type | Voltage or current (configurable) |
| Voltage Output Range | 0–10 V DC |
| Current Output Range | 0–20 mA / 4–20 mA |
| Load Resistance (Voltage) | ≥ 2 kΩ |
| Load Resistance (Current) | ≤ 600 Ω |
| Resolution | 12 bits |
| Accuracy | ±0.1% of full scale |
| Isolation | Channel-to-bus and channel-to-channel |
| Power Supply | 5 V DC (from I/O base) |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions | 25.4 x 273 x 267 mm |
| Weight | 0.62 kg |
FAQ
FAQ
Q1: What types of output signals does the module support?
A1: It supports both 0–10 V DC voltage and 0–20 mA / 4–20 mA current outputs, configurable per channel.
Q2: How many output channels are available on this module?
A2: The 1C31132G01 module provides 8 analog output channels.
Q3: What is the resolution of the analog outputs?
A3: The module offers 12-bit resolution for accurate signal representation.
Q4: Does the module offer channel-to-channel isolation?
A4: Yes, the module provides isolation between channels and between channels and the system bus.
Q5: What are the supported load resistances?
A5: For voltage output, load must be ≥ 2 kΩ; for current output, load must be ≤ 600 Ω.
Q6: What is the operating temperature range of the module?
A6: The module operates from 0°C to 60°C and can be stored between -40°C and 85°C.
Q7: What kind of power supply does this module use?
A7: It is powered by 5 V DC supplied via the I/O base.
Q8: What are the typical applications of this module?
A8: It is commonly used in DCS systems to control analog actuators such as valves, drives, and control elements.
