Technical Specifications
| Parameter | Specification |
|---|---|
| Model | Ovation 1C31147G02 |
| Type | Pulse Accumulator Module |
| System Compatibility | Ovation Distributed Control System |
| Function | Accumulates pulse signals from field devices and transmits to the control system |
| Power Supply Voltage | 24 V DC nominal |
| Power Consumption | Approx. 4 W |
| Input Type | Digital pulse signals |
| Number of Channels | 8 pulse input channels |
| Counting Range | 32-bit or higher |
| Signal Frequency Range | 0–10 kHz |
| Isolation | Channel-to-bus galvanic isolation |
| Communication Interface | Ovation system bus |
| Diagnostic Functions | Pulse monitoring, fault detection, signal validation |
| Redundancy Support | Supported through system configuration |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% RH, non-condensing |
| Protection Class | IP20 |
| Compliance Standards | IEC, CE, and ANSI industrial standards |
| Dimensions | 152 × 107 × 38 mm |
| Weight | 0.8 kg |
FAQ
FAQ
Q1: What is the main function of the Ovation 1C31147G02 module?
A1: The 1C31147G02 accumulates pulse signals from field devices and sends the processed data to the Ovation Distributed Control System.
Q2: How many pulse channels does the 1C31147G02 support?
A2: The module provides 8 pulse input channels.
Q3: What types of signals can the 1C31147G02 handle?
A3: It handles digital pulse signals from various field devices.
Q4: Does the 1C31147G02 provide galvanic isolation?
A4: Yes, all input channels are isolated from the system bus to maintain signal integrity.
Q5: What diagnostic functions are included in the 1C31147G02?
A5: The module provides pulse monitoring, fault detection, and signal validation functions.
Q6: Can the 1C31147G02 be used in redundant configurations?
A6: Yes, redundancy is supported through the Ovation system configuration.
Q7: What is the maximum signal frequency the 1C31147G02 can process?
A7: The module can handle pulse frequencies up to 10 kHz.
Q8: What is the counting range of the 1C31147G02?
A8: The module supports a 32-bit counting range or higher for accumulated pulses.
