Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Analog Output Module |
| Model | Ovation 1C31174G34 |
| Dimensions | 41 x 159 x 108 mm |
| Weight | 0.3 kg |
| Function | Converts digital signals from the Ovation control system into analog outputs for field devices |
| Output Channels | 8 isolated analog output channels |
| Output Signal Types | 4–20 mA or 0–10 VDC (software configurable) |
| Resolution | 12-bit D/A conversion |
| Accuracy | ±0.1% of full scale |
| Output Load | 600 Ω maximum for current, >5 kΩ for voltage |
| Isolation Voltage | 1500 V RMS channel-to-bus and channel-to-channel |
| Power Supply | 24 VDC nominal |
| Communication Interface | Ovation system backplane |
| Diagnostics | Channel fault detection, output monitoring, and communication status |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95%, non-condensing |
| Mounting | Plug-in module for system backplane |
| Certifications | CE, UL, CSA, and industrial EMC compliance |
FAQ
FAQ
Q1: What is the main function of the Ovation 1C31174G34 module?
A1: The 1C31174G34 converts digital signals from the Ovation control system into precise analog outputs for controlling field devices such as valves, actuators, and transmitters.
Q2: What types of analog outputs are supported by this module?
A2: It supports both current (4–20 mA) and voltage (0–10 VDC) output signals, which can be configured through software according to process requirements.
Q3: How many output channels does the 1C31174G34 provide?
A3: The module provides 8 independent and isolated analog output channels, enabling control of multiple devices simultaneously.
Q4: What is the accuracy of the analog outputs?
A4: The module offers high accuracy of ±0.1% of full scale, ensuring reliable and precise control of connected devices.
Q5: How is electrical isolation handled in this module?
A5: Each output channel is isolated up to 1500 V RMS from other channels and the system bus, preventing interference and enhancing operational safety.
Q6: Does the 1C31174G34 include diagnostic features?
A6: Yes, it provides channel fault detection, output signal monitoring, and communication status diagnostics to maintain reliable operation.
Q7: How does the module communicate with the Ovation system?
A7: It interfaces directly with the Ovation system backplane, transmitting analog output values from the controller to the field devices.
Q8: In what environmental conditions can the 1C31174G34 operate reliably?
A8: The module is designed for industrial use, operating effectively within temperatures from 0°C to +60°C and humidity up to 95% non-condensing.
