Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 1C31199G03 |
| Manufacturer | Ovation |
| Product Type | Valve Positioner Control Module |
| Function | Provides precise control and monitoring of valve position in automation systems |
| Input Signal | 4–20 mA DC or digital communication |
| Output Signal | 4–20 mA DC or PWM for actuator control |
| Control Type | PID, proportional, or adaptive control |
| Position Feedback | 4–20 mA or digital feedback |
| Accuracy | ±0.5% of full scale |
| Response Time | < 50 ms |
| Power Supply | 24 V DC nominal |
| Diagnostics | Position error detection, feedback signal monitoring, internal self-test |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 5% to 95% non-condensing |
| Mounting Type | Panel or rack-mounted |
| Communication Interface | Modbus, HART, or proprietary Ovation protocol |
| Compliance | CE, UL, and CSA certified |
| Dimensions | 250 × 180 × 150 mm |
| Weight | 1.8 kg |
FAQ
FAQ
Q1: What is the function of the 1C31199G03 module?
The 1C31199G03 Valve Positioner Control Module is designed to provide accurate control and monitoring of valve positions in process automation systems.
Q2: What input signals does the 1C31199G03 support?
It supports standard 4–20 mA DC input signals and digital communication from the control system.
Q3: What type of output signals does the module provide?
It delivers 4–20 mA DC or PWM signals to drive valve actuators precisely.
Q4: How is valve position feedback handled?
The module accepts 4–20 mA or digital feedback signals from the valve position sensor to ensure accurate control.
Q5: What control methods are supported by the 1C31199G03?
It supports PID, proportional, and adaptive control modes for fine-tuned valve positioning.
Q6: Does the module include built-in diagnostics?
Yes, it features diagnostic functions such as internal self-tests, position error detection, and feedback signal monitoring.
Q7: What communication protocols are compatible with the module?
The 1C31199G03 supports Modbus, HART, and proprietary Ovation communication protocols.
Q8: Under what environmental conditions can the 1C31199G03 operate?
It operates reliably between -20°C and +70°C and withstands humidity from 5% to 95% non-condensing.
