Technical Specifications
| Parameter | Description |
|---|---|
| Product Name | Analog Output Module |
| Model Number | 5X00063G01 |
| Brand | Ovation |
| Type | Analog Output I/O Module |
| Function | Provides analog current or voltage output signals to field devices |
| Number of Channels | 8 isolated output channels |
| Output Signal Range | 4–20 mA or 0–10 V DC (software configurable) |
| Load Resistance | 0–750 Ω (for current output) |
| Accuracy | ±0.1% of full scale |
| Resolution | 12-bit or better digital-to-analog conversion |
| Isolation | 500 V channel-to-bus and channel-to-channel isolation |
| Response Time | < 10 ms per channel |
| Power Supply Voltage | 24 V DC nominal |
| Power Consumption | < 5 W typical |
| Diagnostics | Built-in self-test and output fault detection |
| Communication Interface | Ovation system I/O bus |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5–95% non-condensing |
| Installation | Plug-in module for standard Ovation I/O chassis |
| Dimensions | 150 x 100 x 50 mm |
| Weight | 0.5 kg |
FAQ
FAQ
Q1: What is the main purpose of the Ovation 5X00063G01 Analog Output Module?
A1: It is designed to convert digital control signals from the Ovation controller into analog voltage or current outputs for driving actuators, control valves, and other field devices.
Q2: What types of output signals can the module generate?
A2: The module can generate both 4–20 mA current signals and 0–10 V DC voltage signals, selectable via configuration software.
Q3: How many output channels does this module support?
A3: It provides 8 isolated analog output channels, each capable of independent configuration and signal transmission.
Q4: Is channel isolation provided in the 5X00063G01 module?
A4: Yes, each channel is galvanically isolated to ensure signal integrity and minimize noise interference between outputs.
Q5: What diagnostic features are available on this module?
A5: The module includes built-in self-testing and fault detection to monitor signal quality and detect open or short-circuit conditions.
Q6: How is the module connected to the Ovation control system?
A6: It connects directly through the Ovation I/O bus, allowing seamless integration and communication with the control processor.
Q7: Can the module be used in both voltage and current output modes simultaneously?
A7: Each channel can be independently configured for current or voltage mode, allowing flexible system design according to process requirements.
Q8: What are typical applications for the 5X00063G01 module?
A8: It is widely used for controlling analog actuators, regulating valve positions, managing drive speeds, and interfacing with analog instruments in power generation and process automation systems.
