Technical Specifications
| Parameter | Description |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product Type | CableFast Terminal Block with fuses |
| Accessory / Separate Part Type | Terminal block |
| Accessory Category | Connection accessories |
| Destination | Quantum I/O module |
| Application | Provides 0.8 A group fusing connections |
| Configuration | Arranged in 4 groups of 8 I/O points |
| Terminal Allocation | Each input is allocated 3 terminals |
| Product Compatibility | 140DDI35300, 140DAI35300, 140DAI55300, 140DAI45300, 140DDI85300 |
| Electrical Connection | 1 female SUB-D 50 connector, Captive screw terminal |
| Mounting Support | Standard DIN rail |
| Dimensions (W x H x D) | 105 x 180 x 270 mm |
| Weight | 0.907 kg |
FAQ
FAQ
Q1: What is the primary function of the Schneider 140CFD03200 CableFast Terminal Block?
A1: It provides fused connections in 4 groups of 8 I/O points, ensuring 0.8 A group fusing for Quantum I/O modules.
Q2: How many terminals are allocated for each input?
A2: Each input is allocated 3 terminals.
Q3: Which I/O modules are compatible with the 140CFD03200?
A3: Compatible modules include 140DDI35300, 140DAI35300, 140DAI55300, 140DAI45300, and 140DDI85300.
Q4: What type of electrical connections does this terminal block use?
A4: It uses a female SUB-D 50 connector and captive screw terminals.
Q5: How is the 140CFD03200 mounted?
A5: It is mounted on a standard DIN rail.
Q6: What is the physical size of this terminal block?
A6: The dimensions are 105 mm (W) x 180 mm (H) x 270 mm (D).
Q7: What is the weight of the 140CFD03200?
A7: The weight of the unit is 0.907 kg.
Q8: Is the 140CFD03200 suitable for signal separation applications?
A8: No, it is designed specifically for fused connection grouping in Quantum I/O modules.
