Schneider 140CFK00400 Analog Output Modules

FAQ

Q1: What type of module is the 140CFK00400?
It is a 4-channel analog output module for the Quantum PLC series.

Q2: What output signals does it support?
It supports ±10 VDC, 0–20 mA, or 4–20 mA analog outputs, depending on configuration.

Q3: Does it provide channel isolation?
Yes, it offers both channel-to-channel isolation and isolation from the backplane bus.

Q4: What is its output accuracy?
The typical output accuracy is ±0.1%, suitable for precise industrial control.

Q5: How is the module installed?
It is installed in a Quantum rack slot with front-wired terminals.

Q6: How is the module powered?
It is powered through the Quantum system backplane—no external power is needed.

Q7: Does it support hot-swapping?
No, hot-swapping is not supported. Power must be turned off before replacing.

Q8: What is the operating temperature range?
It operates within a temperature range of 0°C to 60°C.
