Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 140CPS51100C |
| Product Type | Power Supply Module |
| Manufacturer | Schneider Electric |
| Series | Modicon Quantum |
| Input Voltage Range | 100 to 250 V AC |
| Input Frequency | 47 to 63 Hz |
| Output Voltage | 5 V DC |
| Output Current | 8 A nominal |
| Output Power | 40 W typical |
| Efficiency | ≥ 85% |
| Inrush Current | ≤ 30 A at 230 V AC |
| Line Regulation | ±1% |
| Load Regulation | ±2% |
| Ripple and Noise | < 50 mV RMS |
| Protection Features | Overvoltage, Overcurrent, and Short-Circuit Protection |
| Diagnostic Features | Front LED Indicators for Power and Fault Status |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Cooling Method | Natural Convection |
| Mounting Type | Rack or Backplane Mount |
| Communication Compatibility | Compatible with Modicon Quantum PLC System |
| Certifications | CE, UL, CSA, and IEC Standards |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Weight | 0.65 kg |
FAQ
FAQ
Q1: What is the main function of the Schneider 140CPS51100C module?
A1: The 140CPS51100C serves as a regulated power supply module designed to provide a stable 5V DC output to Modicon Quantum PLC systems, ensuring reliable operation of control and communication modules.
Q2: What type of input voltage does this power module support?
A2: It supports a wide AC input voltage range from 100 to 250 volts, making it adaptable to different industrial power environments.
Q3: How does the module protect itself from electrical faults?
A3: The 140CPS51100C includes built-in protection mechanisms such as overvoltage, overcurrent, and short-circuit protection to maintain system stability and prevent damage to downstream components.
Q4: Does the module include any diagnostic indicators?
A4: Yes, it features front-mounted LED indicators that display power status and fault conditions, allowing maintenance personnel to quickly assess system health.
Q5: What is the typical output capacity of this module?
A5: The module delivers a regulated 5V DC output at a nominal current of 8A, which is sufficient to power several modules within a Modicon Quantum PLC rack.
Q6: Can this power supply operate continuously in high-temperature environments?
A6: Yes, it is designed to operate reliably within an ambient temperature range of 0°C to +60°C, ensuring stable performance in demanding industrial settings.
Q7: Is this module compatible with other Quantum series components?
A7: Absolutely. The 140CPS51100C is specifically designed for seamless integration with other Modicon Quantum system modules via the common backplane connection.
Q8: How does the module ensure stable output performance?
A8: Through precise voltage regulation and low ripple noise characteristics, the 140CPS51100C maintains consistent power delivery, minimizing interference with sensitive control electronics.
