Technical Specifications
| Item | Description |
|---|---|
| Manufacturer | Schneider Electric |
| Product Model | 140CPU67160C |
| Product Type | Unity Processor Module |
| Processor Type | Motorola MPC7457 PowerPC RISC Processor |
| Processor Speed | 266 MHz |
| Program Memory Capacity | 4096 kB |
| Data Memory | 2048 kB SRAM, battery-backed |
| Flash Memory | 16 MB |
| Instruction Execution Speed | 0.12 µs/Boolean Instruction |
| Programming Environment | Unity Pro / EcoStruxure Control Expert |
| Communication Ports | Dual Ethernet (10/100 Mbps), Modbus Plus, Modbus, RS-232, RS-485 |
| Integrated Protocols | Modbus TCP/IP, Modbus RTU, Modbus Plus, Ethernet Global Data (EGD) |
| Backplane Compatibility | Quantum Series Backplane |
| Diagnostic Functions | Built-in LED indicators for power, run, communication, and error monitoring |
| Redundancy Support | Yes, supports Hot Standby (HSBY) redundancy |
| Power Requirements | 5 V DC, 1200 mA |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Mounting Type | Rack-mounted (Quantum rack) |
| Dimensions | Package dimensions: 110 x 190 x 325 mm |
| Weight | Package size 1.412 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the Schneider 140CPU67160C used for?
It is a high-performance Unity Processor designed for complex industrial automation and process control applications within Modicon Quantum PLC systems.
Q2: Which programming software is compatible with this processor?
It can be programmed using Unity Pro or EcoStruxure Control Expert software.
Q3: What are the main differences between the 140CPU67160C and 140CPU67060?
The 140CPU67160C features dual Ethernet ports for enhanced network connectivity and faster communication performance.
Q4: Does this processor support redundancy?
Yes, it supports Hot Standby (HSBY) configurations for high system availability.
Q5: What are the memory specifications of this model?
It includes 4096 kB program memory, 2048 kB SRAM (battery-backed), and 16 MB Flash memory.
Q6: What communication protocols are supported?
It supports Modbus TCP/IP, Modbus RTU, Modbus Plus, and Ethernet Global Data (EGD).
Q7: Is it compatible with existing Quantum racks and modules?
Yes, it is fully compatible with all Modicon Quantum backplanes and I/O modules.
Q8: How does the processor indicate operating status?
LED indicators display power, run, communication, and error statuses for real-time monitoring.
