Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 140DAI54000C |
| Product Type | Discrete Input Module |
| Input Points | 64 points |
| Input Voltage Type | 24 VDC Positive |
| Input Voltage Range | 19 to 30 VDC |
| Input Current | 7 mA per point (typical) |
| Input Response Time | 1 ms (typical) |
| Isolation Voltage | 1780 V RMS (logic to field) |
| Power Consumption | 400 mA @ 5VDC |
| Dimensions | 103.9 × 40.3 × 250 mm |
| Weight | 0.31 kg |
| Operating Temperature | 0 to 60 ℃ |
| Storage Temperature | -40 to 85 ℃ |
| Relative Humidity | 5%–95% non-condensing |
| Mounting | Plug-in, rack-mounted |
FAQ
FAQ
Q1: What type of module is the 140DAI54000C?
A1: It is a 64-point 24VDC positive discrete input module.
Q2: What is the input voltage range of this module?
A2: The input voltage range is 19 to 30 VDC.
Q3: What is the typical input current per point?
A3: The typical input current per point is 7 mA.
Q4: Does the module provide isolation protection?
A4: Yes, it provides 1780 V RMS isolation between logic and field sides.
Q5: What are the dimensions and weight of the module?
A5: The dimensions are 103.9 × 40.3 × 250 mm, and the weight is 0.31 kg.
Q6: What is the operating temperature range?
A6: The operating temperature range is 0 to 60 ℃.
Q7: How is the module installed?
A7: It is plug-in type and mounted on a rack.
Q8: What is the input response time of the module?
A8: The typical input response time is 1 ms.
