Technical Specifications
| Parameter | Description |
|---|---|
| Model | 140DDI353000 |
| Type | Low-voltage DC Discrete Input Module |
| Series | Modicon Quantum |
| Number of Inputs | 32 discrete inputs |
| Channel Grouping | 4 groups (8 inputs per group) |
| Input Voltage | 24 V DC |
| Input Voltage Range | 19.2 – 30 V DC |
| Logic Type | Positive logic (Sink) |
| Voltage for Logic “1” | 15 – 30 V DC |
| Voltage for Logic “0” | –3 – 5 V DC |
| Input Current (Logic 1) | ≥ 2 mA |
| Input Current (Logic 0) | ≤ 0.5 mA |
| Input Impedance | ~ 2,500 Ω |
| Absolute Maximum Input | 30 V DC continuous, 56 V DC for 1.3 ms pulse |
| Response Time | ≤ 1 ms (0 → 1 and 1 → 0) |
| Isolation | Channel group ↔ backplane 1,780 Vrms / 1 min; group ↔ group 500 Vrms / 1 min |
| Power Dissipation | 1.7 W + 0.36 W × number of ON inputs |
| Bus Current Requirement | 330 mA |
| Mounting | Rack / module slot |
| Dimensions | Packaging dimensions: 46.5 x 164.5 x 309.7 mm |
| Weight | 0.3 kg |
FAQ
FAQ
Q1: What is the main purpose of 140DDI353000?
A1: To acquire discrete signals from switches, sensors, or push buttons and interface them with PLC or control systems.
Q2: How many inputs does the module support?
A2: Up to 32 discrete inputs.
Q3: What is the required input voltage?
A3: Standard 24 V DC, with an acceptable range of 19.2 – 30 V DC.
Q4: Does the module provide isolation protection?
A4: Yes; isolation between channel groups and backplane is 1,780 Vrms, and between groups is 500 Vrms.
Q5: What is the response time?
A5: ≤ 1 ms, suitable for fast signal detection.
Q6: What are the power consumption and bus current requirements?
A6: Base power consumption 1.7 W, additional per active channel; bus current approximately 330 mA.
Q7: How is it mounted, and what are the module dimensions/weight?
A7: Rack-mountable standard module; packaging dimensions: 46.5 x 164.5 x 309.7 mm; weight approx. 0.3 kg.
Q8: What applications is it suitable for?
A8: Industrial automation systems requiring large-scale digital input acquisition, such as machine control, sensor inputs, factory automation, and process monitoring.
