Technical Specifications
| Parameter | Description |
|---|---|
| Product Range | Modicon Quantum automation platform |
| Product Type | Ethernet network TCP/IP module |
| Concept | Transparent Ready |
| Web Server | Supported (Class B30) |
| Web Services | Diagnostics via predefined web pages, Rack viewer, Data editor |
| Communication Services | SNMP, Bandwidth management, Global Data, I/O scanning, Modbus TCP, FDR |
| Protocol | Ethernet Modbus TCP/IP |
| Physical Interface | MT/RJ (100BASE-FX fiber optic), RJ45 (10BASE-T/100BASE-TX twisted pair) |
| Transmission Rate | 10/100 Mbit/s |
| Redundancy Support | Yes, hot standby redundant architecture |
| Power Supply | Supplied via the rack power supply |
| Local Signaling | 10 MB/100 MB (LED), Coll (LED), Kernel (LED), Fault (LED), RUN (LED), Fduplex (LED), Ready (LED), Link (LED), Active (LED), TxAct/RxAct (LED) |
| Current Consumption | 750 mA at 5 V DC |
| Module Format | Standard |
| Marking | CE |
| Certifications | UL 508, cUL, CSA C22.2 No 142, FM Class 1 Division 2 |
| IP Protection | IP20 |
| ESD Resistance | 4 kV (contact), 8 kV (air), per IEC 801-2 |
| Electromagnetic Field Resistance | 10 V/m (80…1000 MHz) IEC 801-3 |
| Operating Temperature | 0…60 °C (32…140 °F) |
| Storage Temperature | -40…85 °C (-40…185 °F) |
| Relative Humidity | 95% without condensation |
| Operating Altitude | ≤ 4500 m (14763.78 ft) |
| Dimensions (W x D x H) | 103.9 × 40.3 × 250 mm |
| Net Weight | 0.345 kg (0.761 lb) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the 140NOE77101 module?
A1: It enables Ethernet TCP/IP communication for Modicon Quantum PLC systems, supporting web services and diagnostics.
Q2: Does this module support redundant architectures?
A2: Yes, it supports hot standby redundant configurations.
Q3: Which communication protocols does the module use?
A3: It uses Ethernet Modbus TCP/IP.
Q4: What types of network interfaces are available?
A4: It includes MT/RJ for fiber optic and RJ45 for twisted pair Ethernet connections.
Q5: What is the rated current consumption of this module?
A5: The module consumes 750 mA at 5 V DC.
Q6: What certifications does this module comply with?
A6: It is certified under UL 508, cUL, CSA C22.2 No 142, and FM Class 1 Division 2.
Q7: Is the module compatible with web-based monitoring?
A7: Yes, it offers diagnostics via predefined web pages, Rack Viewer, and a data editor.
Q8: What is the environmental operating range of the module?
A8: It operates from 0 to 60°C and supports humidity up to 95% without condensation.
