Technical Specifications
| Parameter | Value |
|---|---|
| Range of Product | Modicon Quantum automation platform |
| Product or Component Type | DIO Head-End Adaptor |
| Product Compatibility | 140CRA21210, 140CRA21220 |
| Number of Ports | 1 Modbus RS232 (twisted pair, redundant copper) |
| 2 Modbus Plus RS485 (twisted pair, redundant copper) | |
| Transmission Rate | 1 Mbit/s |
| I/O Words | 30 Input / 32 Output |
| Diagnostic Checks | RAM, Processor, RAM Address, Checksum |
| Power Dissipation | 4 W |
| Bus Current Requirement | 780 mA |
| Electrostatic Discharge Immunity | 4 kV (contact), 8 kV (air) – IEC 801-2 |
| Electromagnetic Field Immunity | 9.1 V/m (80–2000 MHz) – IEC 801-3 |
| Operating Temperature | 0…60 °C (32…140 °F) |
| Storage Temperature | -40…85 °C (-40…185 °F) |
| Relative Humidity | 95% without condensation |
| Operating Altitude | ≤ 5000 m (16404.2 ft) |
| Standards | UL 508 |
| Product Certifications | CSA, FM Class 1 Division 2, GOST, GL, RINA, RMRS, DNV, C-tick |
| Dimensions (W x D x H) | 103.9 × 40.3 × 250 mm |
| Weight | 0.493 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the 140NOM21200 adaptor?
A1: It serves as a DIO head-end adaptor, enabling communication over Modbus RS232 and Modbus Plus RS485 networks.
Q2: How many communication ports are available on this adaptor?
A2: It has three ports—one for Modbus RS232 and two for Modbus Plus RS485.
Q3: What is the supported transmission rate?
A3: The adaptor operates at a fixed transmission rate of 1 Mbit/s.
Q4: What diagnostics are performed by this module?
A4: It checks RAM, processor status, RAM address integrity, and checksum.
Q5: What is the maximum number of I/O words supported?
A5: It supports 30 input words and 32 output words.
Q6: What environmental conditions can the adaptor withstand?
A6: It can operate between 0–60 °C and withstand humidity up to 95% without condensation.
Q7: What is the required bus current for operation?
A7: The module requires 780 mA bus current.
Q8: Which certifications does the 140NOM21200 hold?
A8: It is certified by CSA, FM (Class 1 Div 2), GOST, GL, RINA, RMRS, DNV, and complies with C-tick and UL 508.
